Model No. D3E-2A160-A9-01
Voltage Type: 220VAC
Motor Type: EC Brushless Rotor Motor
Impeller Diameter: 160mm
Impeller Materialis: PA66
Material habitationi: Ferro Galvanized
Celeritas Imperium: 0-10VDC/PWM
Praesidium Type: IP44
Insulatio Classis: B
Operatio Temperature : - 25 ~ +60
Motor Praesidium: Plus-caliditas, Plus-current, Locked Protected
| Model: No. | afferens System | aestimavit intentione | frequency | Current Rated | Rated potestas | Volo Rated | aer flow | Air OPPRESSUS | sonitus Level |
| B / S | VDC | Hz | A | W | RPM | M³/H | Pa | dBA* | |
| D3E-2A160-A9-01 | Ball | 220 | 50/60 | 0. 9 | 120 | 1150 | 1270 | 815 | 60 |
